Switchboard Matting: Military-Grade

StaticWorx Switchboard Matting is also available in military specification grade MIL-DTL-15562, used by the U.S. Navy.

Military Electrical-Grade Switchboard Matting

Military electrical-grade switchboard matting is manufactured with a combination of flame retardants and smoke suppressants to meet stringent flame and smoke density standards required for MIL-DTL-15562G specification. All military grade rolls are marked on the back with the specification, month, and year of manufacture to guarantee compliance with MIL-DTL-15562G requirements.

StaticWorx Mil Grade Matting is approved for use by all subordinates of the Department of Defense, including the U.S. Navy.

Military electrical-grade switchboard matting is manufactured with a combination of flame retardants and smoke suppressants to meet stringent flame and smoke density standards required for MIL-DTL-15562G specification. All military grade rolls are marked on the back with the specification, month, and year of manufacture to guarantee compliance with MIL-DTL-15562G requirements.

StaticWorx Mil Grade Matting is approved for use by all subordinates of the Department of Defense, including the U.S. Navy.

Our Mil Grade Switchboard matting comes in three types:

Type I: Smooth sheet; comes in a marbleized beige, blue, green, or grey color. Typically used as floor covering for glue-down installations in high voltage areas. Can be installed with heat or chemically-sealed seams to create a watertight protective surface.

Type II: Smooth runner; comes in blue, green, or black color. Designed for single strip use as portable floor mats around electrical devices or electrical areas. Provides the same insulation and fire/smoke resistance as Type I.

Type III: Mat/Runner with raised diamond plate finish; comes in green or grey color. Designed to be used as a removable runner around electrical equipment or areas where electrical hazards may exist. Provides extra slip protection and the same insulation and fire/smoke resistance as Type I.

CompositionPrecision milled vinyl tile of high density resin with a conductive carbon matrix. Pre-consumer recycled content > 10%.
Electrical PerformanceLifetime Warranty
Free from defects in
workmanship and materials
Lifetime Warranty
Sizes12” x 12”
(24” x 24”, 36″ x 36″ available as custom sizes)
MaintenanceNo wax
Adhesive and Spread RateCovers approx. 180 – 220 sq. ft/gal
Gauge3.0 mm
Grounding Material (Supplied with order)One 2”x 24” copper strip installed every 1,000 ft
Trowel Sizes1.6 x 1.6 mm (1/16”x 1/16”) Square Notch
with 1.6 mm (1/16”) Flats

Information and Downloads

Rubber Flooring Products

StaticWorx launched EclipseEC (Electrically Conductive) rubber in 2010 - the industry’s only fault-tolerant, low-charging ESD floor. EclipseEC won the prestigious Seal of Approval from ESD Journal as the only product suitable for Class-0 ESD (electrostatic discharge) applications. It was also recognized by MIT Laboratories as the only product that inhibits static generation regardless of footwear. And it was voted a top, money-saving product by Buildings.


EclipseEC Rubber - our flagship, award-winning line of rubber flooring - is often the preferred choice of architects, contractors and facility managers for cleanrooms, labs, and electronics manufacturing and handling facilities, as well as 24/7 operations such as server rooms, hospitals, data and critical call centers, schools, and more.


With our EclipseGF – Glue Free – EC Rubber, we saw an opportunity to prevent problems with high vapor concrete and to address fast-track construction. EclipseGF rubber use the same high-performance base material as our award-winning EclipseEC rubber tiles and provides all the same benefits–with the added advantage of being glue free and moisture resistant.


Like any resilient flooring material, standard Eclipse rubber requires pre-installation testing of subfloors for vapor, buckets of glue, troweling or spraying, clean-up, curing times, and possible downtime. This can present problems for companies with fast-track projects or those that can’t afford to shut down. With EclipseGF you get a fast, clean installation. And you can bypass vapor testing with EclipseGF.


Designed for world class environments, StaticWorx SD is an attractive hammered rubber product, available in four colors that would please the most discerning architect or designer.


Tough, yet visually appealing, StaticWorx SD Rubber flooring is perfect for hospitals, recovery rooms, universities, schools, emergency response centers, labs, conference rooms and anywhere comfort, performance and durability are needed. Static generation is less than 100 volts according to ESD STM 97.2 (tested with conductive shoes).


Our StatLock interlocking SD rubber tiles, made from 100% recycled and up to 91% post-consumer rubber, are our greenest ESD floor tile to date. Durable enough for heavy-duty environments, StatLock interlocking rubber, with inherent static-control characteristics, is an excellent choice for temporary or transitional spaces. No need to rely on your landlord to take care of your ESD flooring needs. Simply carry the static-dissipative tiles to your location, zip together quickly and efficiently, then unlock and carry out when you’re finished. Best of all StatLock interlocking ESD rubber provides long wear and exceptional value for people searching for a low cost, high performance static-safe floor.



StaticWorx GroundCom Conductive Matting provides anti-static and anti-fatigue protection in environments where personnel, equipment, and products are at risk of injury or damage from static charges.


Manufactured from PVC engineered vinyl, StaticWorx GroundCom Conductive mats consist of a highly conductive cap film bonded to a non-conductive base. Homogeneous distribution of carbon black and proprietary polymers provide a continuous and permanent “conductive” path-to-ground.


Static-control Properties


All Staticworx black conductive matting is tested per ANSI/ESD STM7. 1 and measures in the optimal electrical rating range of 10E4 to 10E6.


StaticWorx Switchboard rubber matting protects workers from electrical shocks generated by high-voltage equipment, such as fuse boxes, control panels, generators, and transformers.


Unlike other StaticWorx products, our Switchboard mats are not conductive. The matting is insulative – with no static control properties. Insulative mats, designed for safety, inhibit the flow of electricity from high-voltage equipment and prevent transfer of electricity to workers.


Our Switchboard matting meets ANSI ASTM D-178, and has dielectric resistance to 30,000 volts.


AisleSafe is the only floor runner and matting on the market that has received The ESD Journal Seal of approval for static-control walking surfaces suitable for class-0 device handling. Attractive and durable, this ESD-safe runner is ideal as a static-free bridge between EPAs ( ESD-protected – or safe – areas.) It can be used as runner, floor mat, or even as permanent flooring material.
