In Part One, we explored why resistance testing alone does not fully predict ESD flooring performance. Materials that test within the same resistance range can behave very differently once installed in operational environments.

So if resistance is only part of the picture, what should architects, engineers, and facility teams evaluate instead?

The answer is not a single test or specification value. Effective ESD flooring evaluation requires understanding how the entire flooring system will perform under actual operating conditions.

Start with the Application Requirements

Not all ESD-controlled environments require the same level of protection. In some applications, relatively high body voltage may be acceptable. In others, even small amounts of charge generation can create operational risk.

For example:

  • Some data center environments may tolerate body voltages approaching 500 volts
  • ANSI/ESD S20.20 manufacturing environments often require performance below 100 volts
  • Class-0 cleanrooms may require control below 10 volts

The sensitivity of the equipment, products, and processes inside the space should always drive flooring selection criteria.

That means the first step is not selecting a flooring category. It is understanding the actual performance requirements of the environment.

Evaluate Walking Body Voltage — Not Just Resistance

Resistance testing measures how effectively a material transports charge to ground.

Walking body voltage testing measures something different: how much charge is generated during movement.

This distinction is critical because charge generation occurs at the interface between:

  • The floor surface
  • The footwear
  • The person moving across the space

An ESD flooring system may demonstrate acceptable resistance values while still allowing significant body voltage generation during normal use.

In many real-world environments, walking body voltage is the more meaningful indicator of ESD performance.

Consider How the Space Will Actually Operate

Operational conditions have a major impact on flooring performance. Many variables can influence long-term ESD behavior. These include:

  • Rolling traffic
  • Mobile carts
  • Robotics
  • Small casters
  • Heavy point loads
  • Continuous movement
  • Cleaning procedures
  • Environmental conditions

This is especially important for flooring systems that rely on dispersed conductive elements embedded within an otherwise insulative material.

While these systems may perform adequately under standardized testing conditions, performance can become inconsistent when contact points are extremely small or highly concentrated.

The result is that laboratory test performance may not always translate directly to operational performance.

Align Flooring Performance with Footwear Reality

Footwear is often one of the most overlooked variables in ESD flooring selection.

Some flooring systems depend heavily on ESD footwear to maintain acceptable performance. However, long-term compliance can vary significantly between facilities and operational teams. Footwear type also matters. For example:

  • Heel straps provide less contact area
  • Full-coverage sole systems create more consistent engagement
  • Standard footwear may generate substantially higher body voltage

In environments where standard footwear is likely to be worn — or where strict footwear controls are difficult to maintain — flooring systems should be evaluated for low charge generation independent of specialized footwear.

The flooring system should align with how the space will actually be used, not simply how it is expected to operate on paper.

Evaluate Performance Over Time

ESD flooring performance is not static. Environmental conditions, wear patterns, maintenance practices, traffic levels, and operational changes all affect long-term behavior.

Laboratory testing provides a snapshot under controlled conditions. The more important question is whether performance remains stable over years of real-world use.

One of the most effective evaluation methods is installing a test area within an active environment and monitoring performance over time under actual operating conditions. This provides insight into how the flooring system behaves:

  • Under traffic
  • With real equipment
  • With actual footwear
  • Within the environmental conditions the space will experience every day

ESD Flooring Should Be Evaluated as a System

For architects, engineers, and facility teams, evaluating ESD flooring is not about adding unnecessary complexity to the specification process.

It is about selecting a system that will continue to control static reliably after installation — not just during laboratory testing.

Resistance values remain important, but they should not be treated as the sole predictor of performance.

The most effective flooring decisions are made by evaluating how the entire system behaves in use:

  • With people
  • With equipment
  • Under movement
  • Over time

Because ultimately, real-world performance is what protects sensitive environments.
