Conductive Flooring
Conductive flooring provides a low-resistance pathway that quickly transports static charges to ground.
Defined by ANSI/ESD standards, conductive floors measure under 10⁶ ohms (10^6 Ω). Because they discharge static electricity more rapidly than dissipative materials, conductive floors are specified in industries where even a small spark could damage sensitive equipment or ignite flammable materials.
Trusted by leading companies across the U.S. and Canada
How Conductive Differs from Dissipative and Antistatic
Conductive, dissipative and antistatic are all terms used to describe static-control flooring. Although often used interchangeably, they are not the same.
Conductive flooring
<10⁶ Ω. Used where static must be discharged very quickly to eliminate risk of equipment damage, fire, or explosion.
Dissipative flooring
10⁶–10⁹ Ω. Slows discharge to avoid potential shock in environments like telecom, data centers, and flight towers.
Antistatic flooring
Refers only to low static generation. It does not indicate resistance or grounding properties and parts of the material made of polymers may be insulative.
Applications for Conductive Flooring
Conductive flooring provides low electrical resistance ideal for applications when fast charge removal is essential for safety or operational integrity. Applications include:
Battery manufacturing plants
Munitions and explosives facilities
Pharmaceutical production involving solvents or flammable chemicals
Semiconductor cleanrooms and electronics assembly lines*
Specialized labs and R&D environments handling volatile materials
Key Points
- Resistance <10⁶ Ω, compliant with ANSI/ESD S20.20, ASTM F150 and IEC 61340-5-1
- Rapid charge dissipation helps prevent catastrophic ignition or equipment failure
- Reduces risk of static-related downtime or costly damage
- Integral part of an ESD-control system (footwear, adhesives, installation, testing)
*Electronics manufacturing and other ANSI/ESD S20.20 programs do not rely solely on conductivity or whether a floor is conductive or static dissipative. In these applications the floor is evaluated as a system, evaluating multiple factors, including charge generation, resistance of a person wearing ESD footwear in combination with the floor and resistance to groundable point. Low flooring resistance alone is not necessarily a good indicator of performance on these other tests.
StaticWorx Conductive Flooring Products
Eclipse EC Rubber
Premium conductive rubber designed for labs, cleanrooms, and high-traffic areas where safety and performance are non-negotiable.
- Resistance consistently <10⁶ Ω
- Low charge generating
- PVC- and Red List-free
- Extreme low outgassing
- Resilient; comfortable underfoot
- Greenguard certified
- Does not use or rely on ESD eax or polish
- Excellent chemical and wear resistance
AmeriWorx Conductive Vinyl Tile
A reliable, modular conductive vinyl tile system for manufacturing and electronics facilities.
- Tight resistance tolerances (<10⁶ Ω)
- Precision-milled, no shrinkage
- 2500 psi; handles heavy weight loads
- Does not rely on wax or polish for conductivity properties
- Durable and Economic
- FloorScore certified
- 100% Made in the USA
GroundWorx Ultra Epoxy
Seamless epoxy system offering a durable, conductive surface for industrial environments.
- Best in class Generation 3 technology
- Monolithic surface resists chemicals and abrasion
- Bonds securely to substrate for long-term performance
- Designed for heavy-duty operations
- Made in the USA
GroundLock Extreme Platinum*
Our highest-performance interlocking flooring, engineered for the most demanding critical environments.
- Low resistance (<10⁶ Ω)
Dense map of conductive granules - Lift and carry, ideal for temporary spaces
- Exceptional durability and impact strength
- Optimized for high-risk, mission-critical facilities
- Use to cover an entire room or install strategically as a floor mat, runner or small island.
*New product: GroundLock Platinum is engineered for extreme ESD applications
Why StaticWorx?
Every ESD flooring application is unique. At StaticWorx, we guide clients through standards, testing, and application-specific requirements to ensure that each floor delivers safe, long-term static protection. From design through installation and maintenance, we’re with you, helping you navigate the flooring process whether it’s defining strategy for a problem subfloor, guiding you through post-installation testing or just answering questions. You can count on us to be there.
Need the right ESD flooring for your application?
Contact us today for technical guidance, product specs, or a custom quote.
Hear it From Our Clients
ESD standards differ, so we provide customized support for every application
and Configuration ManagementEIT, LLC
The photo shows an installation in progress, using ShadowFX, Forest Floor
